Specifications:
Diameter of working spindle: Travel X-axis Travel Y-axis: Travel Z-axis: Travel W-axis: Spindle speed: Spindle taper: Rapid traverse: Rotary Table size: Weight capacity: Main motor: Dimension of machine:
4" 63" 44" 49" 35" 7 - 1120 RPM ISO 50 110 IPM 49" x 49" 6,620 Lbs. 14 HP 264.1" (L) x 135" (W) x 118" (H)
24 Inch Facing Head With Maximum Face Milling Diameter 35.5” Tail Stock Digital Read Out Built In Rotary Table
