Specifications:
Tonnage Capacity:........................................................................................................100
Tons
Bending Capacities:......................................................................................................
5’ x 1/4"; 8' x 3/16"
Overall Length of Bed and Ram:...................................................................................
98” (8’ 2")
Distance Between Housings:.........................................................................................
78” (6’ 6")
Length of Stroke:..........................................................................................................
8"
Open Height: ..........................................................................................................
17"
Closed Height: ............................................................................................................
9"
Depth of Throat: .......................................................................................................... 10"
Width of Bed: .........................................................................................................
3-3/4"
Distance Floor to Top of Bed:.......................................................................................
36"
Speed - Approach:.......................................................................................................
301" / Min.
- Press: .......................................................................................................
20" / Min.
- Return: ..........................................................................................................
225" / Min.
Ram Repeatability:.........................................................................................................
+/- 0.0004"
Motor:
........................................................................................................
AC and Controls
Overall Dimensions (Approx.):....................................................................
152" L-R x 76" F-B x 108" H
Weight (Est.): ..........................................................................................................
18,000 Lbs.
Equipped With:
36" Wysong GC6000 CNC Back Gauge (X, Y1 and Y2) w/ Manual Vertical Adjustment
3" High Wila Manual Bed Deflection Compensation System (Crowning)
Sectional Ram Clamps / 3-1/4" High Lower Die Rail
Electric Foot Switch Operation
Emergency Stop
Bijur Lubrication System
Key Selector Switches for: Off/Inch/Manual/Auto
PRICE:
FOB
Chicago,
IL ..................................................................................................$27,500 |
